A world module that retrieves triangle data that should be used for building navmeshes at runtime. More...
#include <NavmeshGeoWorldModule.h>
Public Member Functions | |
| virtual void | RetrieveGeometryInArea (plUInt32 uiCollisionLayer, const plBoundingBox &box, plDynamicArray< plNavmeshTriangle > &out_triangles) const =0 |
 Public Member Functions inherited from plWorldModule | |
| plWorld * | GetWorld () |
| Returns the corresponding world to this module. | |
| const plWorld * | GetWorld () const |
| Returns the corresponding world to this module. | |
| plUInt32 | GetWorldIndex () const |
| Same as GetWorld()->GetIndex(). Needed to break circular include dependencies. | |
| Public Member Functions inherited from plReflectedClass | |
| virtual const plRTTI * | GetDynamicRTTI () const |
| bool | IsInstanceOf (const plRTTI *pType) const |
| Returns whether the type of this instance is of the given type or derived from it. | |
| template<typename T > | |
| PL_ALWAYS_INLINE bool | IsInstanceOf () const |
| Returns whether the type of this instance is of the given type or derived from it. | |
Protected Member Functions | |
| plNavmeshGeoWorldModuleInterface (plWorld *pWorld) | |
| Protected Member Functions inherited from plWorldModule | |
| plWorldModule (plWorld *pWorld) | |
| void | RegisterUpdateFunction (const UpdateFunctionDesc &desc) |
| Registers the given update function at the world. | |
| void | DeregisterUpdateFunction (const UpdateFunctionDesc &desc) |
| De-registers the given update function from the world. Note that only the m_Function and the m_Phase of the description have to be valid for de-registration. | |
| plAllocator * | GetAllocator () |
| Returns the allocator used by the world. | |
| plInternal::WorldLargeBlockAllocator * | GetBlockAllocator () |
| Returns the block allocator used by the world. | |
| bool | GetWorldSimulationEnabled () const |
| Returns whether the world simulation is enabled. | |
| virtual void | Initialize () |
| This method is called after the constructor. A derived type can override this method to do initialization work. Typically this is the method where updates function are registered. | |
| virtual void | Deinitialize () |
| This method is called before the destructor. A derived type can override this method to do deinitialization work. | |
| virtual void | OnSimulationStarted () |
| This method is called at the start of the next world update when the world is simulated. This method will be called after the initialization method. | |
| virtual void | WorldClear () |
| Called by plWorld::Clear(). Can be used to clear cached data when a world is completely cleared of objects (but not deleted). | |
Additional Inherited Members | |
| Static Public Member Functions inherited from plNoBase | |
| static const plRTTI * | GetStaticRTTI () |
| Protected Types inherited from plWorldModule | |
| using | UpdateFunction = plDelegate<void(const UpdateContext&)> |
| Update function delegate. | |
| Protected Attributes inherited from plWorldModule | |
| plWorld * | m_pWorld |
A world module that retrieves triangle data that should be used for building navmeshes at runtime.
If a physics engine is active, it usually automatically provides such a world module to retrieve the triangle data through physics queries.
In other types of games, a custom world module can be implemented, to generate this data in a different way. If a physics engine is active, but a custom method should be used, you can write a custom world module and then use plWorldModuleFactory::RegisterInterfaceImplementation() to specify which module to use. Also see plWorldModuleConfig.
